CBY Series chocolate coating pan

CBY Series chocolate coating pan
Product name : CBY Series chocolate coating pan
Details :


CBY SERIES COATING PAN

(MODEL: CBY600,800,1200,1250)


Profile:



FUDE MACHINERY supply the CBY Series coating pan, which is mainly used for ball shape, grain shape materials mixing, polishing, coating etc..in confectionery, pharmaceutical, or other light industry. Such as the chocolate bean, jelly bean, nuts coating, pills, etc..

This machine is mainly consists of frame body, worm and screw driving system, stainless steel pan, heater and fan (optional), controlling system. The pan is driving by worm wheel and motor. With the centrifugal effect the grains are rolling and attrition in the pan with other materials such as chocolate, sugar, glue materials etc..to be coated or polished.



Specifications:

MODEL

CBY600

CBY800

CBY1000

CBY1250

Diameter (mm)

600

800

1000

1250

Capacity (kg/batch)

15

30-40

50-70

80-150

Rotary speed

(r/min)

36

36

32

28

Motor Power

(kW)

0.75

1.1

1.1

1.5

Fan Power

(kW)

0.15

0.15

0.15

0.3

Heater

Power (kW)

1

2

2

3

Shell size

(L*W*H)mm

800*600 *900

1000*800 *1430

1000*1000 *1500

1250*1200 *1820

Weight (kg)

85

205

220

350
